Cardiac CTA LAD Calcification, AiCE

Aquilion Prime SP

Cardiac CTA with AiCE DLR demonstrating good visualization of lumen in the presence of calcified plaque, through low-noise and high-resolution characteristics

View Scan Parameters

Scan Mode Ultra-Helical
Collimation 0.5mm x 80
kVp 120
mAs EC
Rotation Time 0.5s
Scan Range 167.0mm
Reconstruction AiCE Cardiac
CTDIvol 7.2mGy
DLP 140.8mGy·cm
Effective Dose 0.6mSv
k-factor 0.014 (AAPM Report 96)
Aquilion Prime SP Cardiac CTA LAD Calcification, AiCE
Aquilion Prime SP Cardiac CTA LAD Calcification, AiCE
Aquilion Prime SP Cardiac CTA LAD Calcification, AiCE
Aquilion Prime SP Cardiac CTA LAD Calcification, AiCE
Aquilion Prime SP Cardiac CTA LAD Calcification, AiCE
Aquilion Prime SP Cardiac CTA LAD Calcification, AiCE
× 拡大画像

Cardiac CTA

Aquilion Prime SP

Prospective Cardiac CTA (HR 52 bpm)

View Scan Parameters

Scan Mode Ultra-Helical
Collimation 0.5mm x 80
kVp 100
mAs SUREExposure
Rotation Time 0.35s
Scan Range 106.0mm
Reconstruction AIDR 3D
CTDIvol 6.7mGy
DLP 92.4mGy·cm
Effective Dose 1.29mSv
k-factor 0.014 (AAPM Report 96)
Aquilion Prime SP Cardiac CTA
Aquilion Prime SP Cardiac CTA
Aquilion Prime SP Cardiac CTA
Aquilion Prime SP Cardiac CTA
Aquilion Prime SP Cardiac CTA
Aquilion Prime SP Cardiac CTA
× 拡大画像

Cardiac CTA Coronary Artery Fistula

Aquilion Prime SP

Cardiac CTA demonstrates a fistula connecting the LAD to an aneurysm adjacent to the right ventricle.

View Scan Parameters

Scan Mode Ultra-Helical
Collimation 0.5mm x 80
kVp 120
mAs SUREExposure
Rotation Time 0.35s
Scan Range 160.0mm
Reconstruction AIDR 3D
CTDIvol 26.1mGy
DLP 498.1mGy·cm
Effective Dose 6.97mSv
k-factor 0.014 (AAPM Report 96)
Aquilion Prime SP Cardiac CTA Coronary Artery Fistula
Aquilion Prime SP Cardiac CTA Coronary Artery Fistula
Aquilion Prime SP Cardiac CTA Coronary Artery Fistula
Aquilion Prime SP Cardiac CTA Coronary Artery Fistula
Aquilion Prime SP Cardiac CTA Coronary Artery Fistula
Aquilion Prime SP Cardiac CTA Coronary Artery Fistula
× 拡大画像

Cardiac CTA LAD Stents, RCA Mixed-Plaques

Aquilion Prime SP

Prospective Cardiac CTA demonstrates thin coronary arteries, patent overlapping stents in the LAD and mixed plaques in RCA

View Scan Parameters

Scan Mode Ultra-Helical
Collimation 0.5mm x 80
kVp 120
mAs 111
Rotation Time 0.35s
Scan Range 110.0mm
Reconstruction AIDR 3D
CTDIvol 21.0mGy
DLP 298.9mGy·cm
Effective Dose 4.1mSv
k-factor 0.014 (AAPM Report 96)
Aquilion Prime SP Cardiac CTA LAD Stents, RCA Mixed-Plaques
Aquilion Prime SP Cardiac CTA LAD Stents, RCA Mixed-Plaques
Aquilion Prime SP Cardiac CTA LAD Stents, RCA Mixed-Plaques
Aquilion Prime SP Cardiac CTA LAD Stents, RCA Mixed-Plaques
