Aquilion Lightning 80

Canon's comprehensive suite of Adaptive Diagnostic imaging solutions that simplify complex protocols and provide consistent quality results.

Advanced intelligent Clear-IQ Engine (AiCE) is now available on Aquilion Lightning 80.

Menu

Ankle

Aquilion Lightning 80

Ankle scan reconstructed with AiCE

View Scan Parameters

Scan Mode Ultra-Helical
Rotation Time 0.75 s
CTDl 3.8 mGy
DLP 60.6 mGy.cm
Effective Dose
k factor n/a
Aquilion Lightning 80 Ankle
Aquilion Lightning 80 Ankle
Aquilion Lightning 80 Ankle
Aquilion Lightning 80 Ankle
× 拡大画像

AiCE with SEMAR

Aquilion Lightning 80

Ankle scan with internal fixation reconstructed with AiCE and SEMAR

View Scan Parameters

Scan Mode Ultra-Helical
Rotation Time 0.75 s
CTDl 3.8 mGy
DLP 60.6 mGy.cm
Effective Dose
k factor n/a
Aquilion Lightning 80 AiCE with SEMAR
Aquilion Lightning 80 AiCE with SEMAR
× 拡大画像

Pelvis with SEMAR

Aquilion Lightning 80

80-year-old woman had undergone bilateral total hip replacement. A CT scan of the pelvis with SEMAR was performed for evaluation.

View Scan Parameters

Scan Mode Ultra-Helical
Metal Artifact Reduction SEMAR
CTDlvol 8.7 mGy
Effective Dose 4.89 mSv
k-factor 0.015 (AAPM Report 96)
Aquilion Lightning 80 Pelvis with SEMAR
Aquilion Lightning 80 Pelvis with SEMAR
Aquilion Lightning 80 Pelvis with SEMAR
Aquilion Lightning 80 Pelvis with SEMAR
× 拡大画像

Right Shoulder

Aquilion Lightning 80

82-year-old man fell onto his right shoulder. An X-ray showed a fracture of the head of the humerus. A CT scan of the right shoulder was performed to further evaluate the injury.

View Scan Parameters

Scan Mode Ultra-Helical
Collimation 0.5mm x 80
CTDIvol 14.2 mGy
Effective Dose 3.53 mSv
k-factor 0.014 (AAPM Report 96)
Aquilion Lightning 80 Right Shoulder
Aquilion Lightning 80 Right Shoulder
Aquilion Lightning 80 Right Shoulder
Aquilion Lightning 80 Right Shoulder
Aquilion Lightning 80 Right Shoulder
Aquilion Lightning 80 Right Shoulder
Aquilion Lightning 80 Right Shoulder
Aquilion Lightning 80 Right Shoulder
Aquilion Lightning 80 Right Shoulder
Aquilion Lightning 80 Right Shoulder
× 拡大画像

Vertical Patella Fracture

Aquilion Lightning 80

A CT scan of the right knee following a sport injury demonstrates a vertical fracture of the patella

View Scan Parameters

Scan Mode Ultra-Helical
Collimation 0.5mm x 80
kVp 120
mAs 100
Rotation Time 0.5s
Scan Range 192.0mm
Reconstruction AIDR 3D
CTDIvol 12.0mGy
DLP 282.1mGy·cm
Effective Dose
k-factor
Aquilion Lightning 80 Vertical Patella Fracture
Aquilion Lightning 80 Vertical Patella Fracture
Aquilion Lightning 80 Vertical Patella Fracture
Aquilion Lightning 80 Vertical Patella Fracture
Aquilion Lightning 80 Vertical Patella Fracture
Aquilion Lightning 80 Vertical Patella Fracture
× 拡大画像
