Advanced intelligent Clear-IQ Engine (AiCE) Brain

Aquilion Exceed LB

A non contrast brain scan reconstructed with AICE demonstrates excellent gray white differentiation and noise free images.

View Scan Parameters

Scan Mode Ultra-Helical

Collimation 0.5 mm x 80

kVp 120

mAs SUREExposure

Rotation Time 1.0 s

Scan Range 185 mm

Dose Reduction AiCE

CTDIvol 57.3mGy

DLP 1322.6mGy·cm

Effective Dose 2.78 mSv

k-factor 0.0021 (AAPM Report 96)

Aquilion Exceed LB Advanced intelligent Clear-IQ Engine (AiCE) Brain

×

Neck with SEMAR

Aquilion Exceed LB

A non contrast scan of the neck was reconstructed with AiCE and SEMAR. AiCE dramatically reduces the noise while SEMAR removes the artifact from the dental fillings

View Scan Parameters

Scan Mode Ultra-Helical

Collimation 0.5 mm x 80

kVp 120

mAs SUREExposure

Rotation Time 0.5 s

Scan Range 213.0 mm

Dose Reduction AiCE

CTDIvol 14.6mGy

DLP 375.5mGy·cm

Effective Dose 1.46 mSv

k-factor 0.0039 (AAPM Report 96)

×

AiCE Chest

Aquilion Exceed LB

A non contrast scan of the chest was reconstructed with AiCE. AiCE Lung dramatically reduces the image noise and maintains the spatial resolution of the lung parenchyma

View Scan Parameters

Scan Mode Ultra-Helical

Collimation 0.5 mm x 80

kVp 120

mAs SUREExposure

Rotation Time 0.5 s

Scan Range 700 mm

Dose Reduction AiCE

CTDIvol 4.9mGy

DLP 367.7mGy·cm

Effective Dose 5.15 mSv

k-factor 0.014 (AAPM Report 96)

×

AiCE Cardiac

Aquilion Exceed LB

A retrospective ECG gated scan of the heart was performed in this patient with a heart rate of 70bpm and reconstructed with AiCE.

View Scan Parameters

Scan Mode Ultra-Helical

Collimation 0.5 mm x 80

kVp 120

mAs SUREExposure

Rotation Time 0.4 s

Scan Range 135mm

Dose Reduction AiCE

×

AiCE Abdomen and Pelvis

Aquilion Exceed LB

A scan of the abdomen & pelvis was performed in Arterial and portal phases and reconstructed with AiCE.

View Scan Parameters

Scan Mode Ultra-Helical

Collimation 0.5 mm x 80

kVp 100

mAs SUREExposure

Rotation Time 0.5 s

Scan Range 630 mm

Dose Reduction AiCE

CTDIvol 8.2mGy

DLP 557.1mGy·cm per phase

Effective Dose 16.71 mSv

k-factor 0.015 (AAPM Report 96)

Aquilion Exceed LB AiCE Abdomen and Pelvis

×

AiCE Abdomen & Pelvis

Aquilion Exceed LB

A scan of the abdomen & pelvis was performed and reconstructed with AiCE. Arterial phase iodine maps created with Subtraction SCT demonstrate an enhancing tumor in the abdomen. A large collection with inflammatory tissue is seen in the right groin. Both masses are clearly visualized in grey-scale and color SCT.

View Scan Parameters

Scan Mode Ultra-Helical

Collimation 0.5 mm x 80

kVp 80

mAs SUREExposure

Rotation Time 0.5 s

Scan Range 490 mm

Dose Reduction AiCE

CTDIvol 3.7mGy

DLP 197.4mGy·cm per phase

Effective Dose 8.89 mSv

k-factor 0.015 (AAPM Report 96)

Aquilion Exceed LB AiCE Abdomen & Pelvis

×

vHP Chest

Aquilion Exceed LB

A scan of the chest was performed to rule out coronary artery disease and pulmonary emboli. A vHP scan was performed utilizing a retrospective ECG gated scan of the heart and a non gated scan of the remaining chest. Perfusion defects are seen in the iodine maps corresponding to pulmonary emboli.

View Scan Parameters

Scan Mode Ultra-Helical

Collimation 0.5 mm x 80

kVp 120

mAs SUREExposure

Rotation Time 0.4 s

Scan Range 261mm

Dose Reduction AiCE

×

Hips

Aquilion Exceed LB

AiCE provides excellent low noise images. The bone reconstruction provides excellent spatial resolution. Courtesy Radiotherapeutic Institute Friesland, the Netherlands

View Scan Parameters

Scan Mode Ultra-Helical

Collimation 0.5 mm x 80

kVp 120

mAs SUREExposure

Rotation Time 0.5 s

Scan Range 320 mm

Dose Reduction AiCE

CTDIvol 10.1 mGy

DLP 369.1 mGy·cm

Effective Dose 5.54 mSv

k-factor 0.015 (AAPM Report 96)

×

Foot Fracture

Aquilion Exceed LB

Fractures of the metatarsals are seen in this scan of the foot reconstructed with AiCE. AiCE Bone removes the image noise while maintaining the excellent spatial resolution.

View Scan Parameters

Scan Mode Ultra-Helical

Collimation 0.5 mm x 80

kVp 120

mAs SUREExposure

Rotation Time 0.5 s

Scan Range 205mm

Dose Reduction AiCE

CTDIvol 1.6mGy

DLP 40.1mGy·cm

×
